Run btvs.exe in Ellisys mode on the machine to be traced: btvs.exe -Mode EllisysĪ.

Select the HCI Overview (injection) overview tab.

If only HCI traces are desired, uncheck all of the options under Wireless Capture.

Configure recording options in Record-> Recording options in the Ellisys Bluetooth Analyzer.

In Tools-> Options in the Ellisys Bluetooth Analyzer, enable HCI injection services on the Injection API tab.

Run wireshark and pass in the ip address of the first machine and chosen port via command line parameters: wireshark -k -i port defaults to 24352Īssumes Ellisys is installed.

Run btvs.exe using the command prompt\Powershell console: btvs.exe -Mode Wireshark -Remote on.

Otherwise, manually start Wireshark and provide the default TCP pipe as the interface: wireshark -k -i for Wireshark on separate machine

If Wireshark is installed, Wireshark will automatically open.

Run btvs.exe using the command prompt\PowerShell console: btvs.exe -Mode Wireshark.

Usage for Wireshark on same machine (recommended) Clicking again extends the time.Īssumes Wireshark is installed. For example, large ACL packets, sensitive data including encryption keys and HID reports.įor a limited time, enable SSP debug mode. There are two buttons on the Bluetooth Virtual Sniffer window:Ĭauses data to be collected in the HCI logs that would normally be dropped. (Default: 1)Īll of these usages require opening a command prompt or Powershell console and navigating to btvs application inside the extracted BTP folder. Service (Ellisys mode only) Specifies the HCI Injection Service.ġ: Primary. Off will try to start Wireshark on the same machine. Remote (Wireshark only) Specifies whether Wireshark will be on the same machine Port (Ellisys or Wireshark only) Specifies the UDP listen port of theĮllisys Bluetooth Analyzer injection API\Specifies the TCP port

Mode Optionally specify whether btvs.exe should generate traces Command line options btvs.exe Īddress (Ellisys mode only) Specifies the IP address of the machine The Bluetooth Virtual Sniffer allows the user to view live HCI traces in the Frontline Protocol Analysis System, in the Ellisys Bluetooth Analyzer, or in Wireshark.
